Drafting: State of the art software and hands on knowledge creates unmatched Value Engineering!

AutoCAD DrawingsIt starts with Autodesk AutoCAD 2007 drafting software, using LISP programs and parametric automation to drive drafting of parts, assemblies and unit drawings.

If possible these drawings may already be drawn reducing time and cost of a project significantly. Many Customers have multiple products and stone areas they are trying to get so our drafting department often is in direct communication with the architects, builder or buyer to ensure proper design of given stones.

Our drafters can add design assemblies, installation drawings and other valuable documentation that makes our cast stone products much easier to install. We have 3 world-renowned artists that can add decorative and ornamental designs to customize your cast stone.

Drawings: Every Stone can be custom drawn to meet your needs!

The initial preliminary quote often includes a submittal package of drawings for each Unit and/or Parts. These drawings include Unit Line Drawings, Assembly drawings, Part sheets, and attachment drawings.

These drawings can then be used to help both masons and architects in making decisions on what might need to be customized or what can be standardized.

Many customers want to order linear foot parts and then field cut them on site to fit. We offer linear foot pricing and generally include Part drawings with these types of quotes. We also have several helpful drawings that detail field cutting, flashing and other installation decisions to help make your masonry decisions more aesthetically pleasing.

Our goal in drafting is to add value, reduce masonry costs and provide our customers the benefits of our substantial cast stone knowledge!

Stone Legends' Drafting Department
